DESCRIPTION

FLOOR PLANS

FULL SPEC

Exterior Details
Footprint 8' x 24'
Total Area 241 sq ft
House Height (exc trailer) 11'
Interior Details
Living Area 7'-4" x 8'-8"
Bathroom 7'-4" x 2'-8"
Loft 7'-4" x 11'-7"
Kitchen 7'-4" x 8'-9"
Ceiling Height - Kitchen 6'-1"
Ceiling Height - Loft 3'-3"
Self-Build Cost
$26,500

WHAT’S INCLUDED IN THIS PLAN SET

Example Plan Set
Cover Page & EULA
  • Full-color exterior rendering of the tiny house
  • Full copy of the End User License Agreement
Foundation Details
  • Construction details for fastening and building the house on a trailer
  • Construction details for a permanent, footing and block wall foundation
Exterior Elevations & Roof Plan
  • Annotated elevation drawings for the front, back, left and right
  • Annotated roof plan with pitch
Floor Plans
  • Construction floor plan, detailing door and window locations
  • Architectural floor plan, detailing rooms and features
Electrical & Water Schematic
  • Suggested location of electrical outlets and fixtures
  • Suggested pipe runs for fresh, grey and black water
Framing Plans
  • Detailed construction plans for the floor, wall and roof framing
  • Detailed construction plans for internal partition walls
  • Detailed construction plans for any ancillary framing
Cabinetry Construction
  • Construction details for any custom cabinetry
Building Section
  • Annotated building section details of flloor, walls and roof
  • Generic exterior wall and roof details
Components
  • Details of any house-specific furniture, fittings and fixtures
